SM-J600A Smoke Purify Machine

SM-J600A Smoke Purify Machine

SM-J600A Smoke Purify Machine
SM-J600A Smoke Purify MachineSM-J600A Smoke Purify MachineSM-J600A Smoke Purify MachineSM-J600A Smoke Purify Machine
CategoriesSmoke Purify Machine
BrandSAMTRONIK
ModelSM-J600A
FOB portShenZhen HongKong
Terms of PaymentL/C, D/A, D/P
Update TimeMar 29,2024
Detail Information

Application:

For laser cutting, laser marking, laser carving, grinding and cutting and other occasions generated by the smoke, dust, odor, toxic and harmful gases, it has a good purification and filtration effect.


The appearance is simple and elegant. Integrated design of fuselage, metal frame structure, high-quality cold-rolled steel plate electrostatic spraying process, durable;


The humanized operation panel is more classic and exquisite, full of scientific and technological content, which is refreshing;


The inlet and outlet flange can be flexibly prepared according to the demand;


Filter quick removal design, convenient and efficient replacement;


The brushless DC motor with built-in controller ensures better performance and quality;


Stable operation, low noise, high efficiency, low energy consumption and long working time.


The wind wheel adopts eddy current backward design and special alloy material to effectively prevent the wind wheel from being corroded. The unique dynamic balance correction technology makes the wind turbine run more stable and reliable. High air volume, high suction, higher filtration rate;


Adopt multiple filtration design. Filter layer by layer to ensure that the harmful dust is filtered more thoroughly. The highest purification rate was 99.9%;


Modular design, layer by layer protection. The filter of each layer can be replaced separately, so the service life of the filter is longer and the replacement cost is lower.



Pass CE certification (CertificateNo.: ast-2016080001emc / ast-2016080001LVD)

Pass the pony certification (CertificateNo.: mdbrjc0u01615555)

Design standard: indoor air qualitystandard, gb21551.1-2008, GB / T 18801.

Specification

Dimensionmm

500*420*1140(LWH

Power input

AC220V 50Hz

Power

600W

Flow

Max 800m³/h

Filtration

Max 0.3μm 99.9%

Noise

<65dB

Wind pressure

3800Pa(inner)

Air inlet and outlet

                                    φ150mm

Weight

75kg
